Schilling PL Slide
Sliding and lift-sliding door system
Distinguishing features
High insulation
Thermal insulation was obtained by using thermal spacers in the glazing plane and by dividing the construction zones into: thermally insulated and non-insulated.
Versions
Available in sliding and lifting-sliding versions.
Up to 200 kg
Schilling PL Slide allows the use of wings weighing up to 200 kg in the sliding and lifting-sliding version
Fittings
Fittings mounted in Eurorowek
Technical data
Profile diemnsions
One-rail frame 106 mm, two-rail 94 mm, three-rail 155 mm; Wing 46 mm
Maximum sliding wing weight
Up to 200 kg (110 mm version), up to 80 kg (86 mm version)
Maximum lift-slide wing weight
Up to 200 kg (110 mm version), up to 120 kg (86 mm version)
Air permeability
Class 4 acc. PN 1026
Water resistance
E 1050 acc. PN-EN 1027
Glazing thickness
20-24 mm
Glazing width
29-33 mm (110 mm version), 20-24 mm (86 mm version)
Schilling PL Slide
- High insulation
- Wings weight up to 200 kg
- Available in sliding and lifting-sliding versions.
